Product EA5R450XKQ


Measuring Light Screen

Receiver

    • Male M12 × 1, 8-pin
    • Protection class IP65
    • Resolution 5 mm
    • Max. range 4 m
    • 2 × EZA-MBK-11 brackets included in delivery
    • Operating voltage 18…30 VDC
    • IO-Link communication and PNP switching output (standard via IO-Link splitter CSB-M1240M1280 included in scope of delivery) or analog output 0…10 V via splitter CSB-M1250M1280 (to be ordered separately)
    • Extension cable required between emitter and splitter, type DEE2R-8xxD
    • 2 × PNP switching output (SIO mode)
    • 2 × analog outputs 0…10 V (SIO mode)
